SH-222

Specifications
  • Inputs:
  • Outputs:
  • Peak Music Power:
  • Speaker:
  • T.H.D:
  • Wireless Service Range:
  • Frequency Channel:
  • Operating Temperature:
  • Frequency Range:
  • Dimensions WxDxH:
  • Gross Weight:
  • Machine Body Material:
  • 1 Wired Microphone Inputs
  • 1 AUX Output
  • 50 Watts Max
  • 1 full range 4Ω 6.5” speaker
  • <1%
  • 35m max in VHF receiver module
  • Single / double wireless channels
  • -25ºC to 50ºC
  • VHF 165-265MHz
  • 180x110x300mm
  • 2.7 kgs
  • ABS Engineering Plastic Body
Features

• 1 wireless microphone (Handheld, lapel mic or headset mic option).
• Without DC8.4V rechargeable battery charger.
• Built-in one DC 12V -- 1.2AH rechargeable battery.





SH-822

Specifications
  • Inputs::





  • Outputs:
  • Peak Music Power:
  • Speaker:
  • T.H.D:
  • Wireless Service Range:
  • Frequency Channel:
  • Operating Temperature:
  • Frequency Range:
  • Dimensions WxDxH:
  • Gross Weight:
  • Machine Body Material:
  • 1 Φ6.5mm dynamic microphone input jack, 1 Φ3.5mm
    cendenser microphone input jack, 1 AUX input jack.
    1 USB input port.
    1 SD card input slot.
  • 1 AUX Output
  • 50 Watts Max
  • 1 full range 4Ω 6.5” speaker
  • <5%
  • 35m max in VHF receiver module
  • Single Channel
  • -25ºC to 45ºC
  • VHF 165-265MHz
  • 180x300x110mm
  • 2.4 kgs
  • ABS Engineering Plastic Body
Features

• 1 wireless microphone (Handheld, lapel mic or headset mic option)
• With USB/SD card slot
• DC8.4V rechargeable battery charger
• Built-in one DC 12V -- 1.2AH rechargeable battery





SH-677U

Specifications
  • Inputs:
  • Outputs:
  • Peak Music Power:
  • Speaker:
  • T.H.D:
  • Frequency Channel:
  • Wireless Service Range:
  • Operating Temperature:
  • Frequency Range:
  • Dimensions WxDxH:
  • Gross Weight:
  • Machine Body Material:
  • 4 Wired micnputs & 3 AUX inputs
  • 1 AUX & 1 4Ω ext. speaker output
  • 100 Watts Max
  • 1 2Ω fullrange 8” spker & 1 8Ω 1.5 Horn
  • <5%
  • Dual Channels
  • 35m max in VHF receiver module
  • -25ºC to 45ºC
  • VHF 165-265MHz
  • 322x170x435mm
  • 7.2 kgs
  • ABS Engineering Plastic Body
Features

• One wireless microphone (Handheld, lapel mic or headset mic option)
• With USB/SD card slot
• DC8.4V rechargeable battery charger
• Built-in one DC 12V -- 7AH rechargeable battery





SH-181U

Specifications
  • RMS:
  • Output power:
  • Power Supply:
  • Frequency response:
  • Distortion Factor:
  • Audio input:
  • Operating temparature:
  • Dimensions (WxHxD):
  • Weight:
  • 10W max, THD <20% in full battery level
  • 15W max, DC 9V input
  • Built-in DC7.4V/220mAH Lith. batt 4ohm
  • 100Hz-15KHz (-3dB)
  • <1% (1W)
  • Stereo 250mV/1K
  • -10˚C -45˚C
  • 127x103x48.5mm
  • 320g
Application

Political Campaigns, Teachings, Assemblies, Conferences,
Church Services, Parades, Lectures, Auctions, Sales Promotion,
Tour Guide, etc.





SH-181U

Specifications
  • Speaker:
  • Impedance:
  • Power Supply:
  • Peak Music Power:
  • RMS:
  • Frequency Response:
  • Distortion Factor:
  • Audio Input:
  • Operating Temperature:
  • Dimension:
  • Weight:
  • 3”
  • 4 Ohms
  • Built-In DC 1.4V/1000 mAHLithium Batt.
  • 10 Watts Max
  • 6W Max, THD <20% in Full Battery Level
  • 100H-20KHz-3dB100Hz>8dB10KHz>8dB
  • <1% (1W)
  • Double Channel 250mV/1K
  • 20 - 45°C
  • 104mm x 86mm x 42.50mm
  • 245g
Application

Political Campaigns, Teachings, Assemblies, Conferences,
Church Services, Parades, Lectures, Auctions, Sales Promotion,
Tour Guide, etc.
